How to Configure Datalogic Scanners for Smartphone Reading
Share
The world of commerce has changed over the years and has evolved to allow for greater fluidity in sales and greater speed, to adapt to today's rhythms. If before you could afford to waste time in stores when making purchases, taking advantage of that moment of shopping to also have a chat with the seller, today life is more frenetic and you have to run .
Here technology has come to our rescue, and almost every purchasable object is recognizable through its own specific code, the barcode , which contains all the information about the object, making it immediately available.
To be able to acquire this information, we obviously need a specific reader, and one of the leaders in the market is the Datalogic brand, which is used in retail, not only in the food sector, to offer customers a fast transaction or in any case fast acquisition of information. The applications of scanners are many, as are the models available.
For payments at checkout counters, whether staffed or automated and self-service, for managing returns, for disposing of loads in the warehouse, in short for any use, the Datalogic catalogue offers suitable solutions with bi-optic or single-plane scanner models, customisable according to the customer's needs and requirements.
Datalogic Scanner Models
Datalogic offers models that can be adapted to every need and type of business, with fixed countertop scanners and manual ones, some even wearable, which allow you to have your hands free when necessary to carry out other operations at the same time.
Designed primarily for the logistics and transportation market, they offer rapidity in movement, increasing productivity; they are also lightweight and the battery life ensures prolonged use. As well as the wireless barcode reader, which without the clutter of cables guarantees maximum speed, a long battery life and a large memory for scanning.
Whichever model you choose from the wide range available on the official website, the first thing to do upon first use will be to configure the barcode reader , and this will be easy to do using the specific manual that will accompany each piece purchased, made available by the parent company.
Read from smartphone
In some cases it will be very useful if not necessary to be able to use a reader by connecting it to a smartphone or tablet, so as to be able to read the barcode directly on the display of the chosen device. Let's also see how we can configure a Datalogic scanner by following some simple instructions to be able to read even the 2D codes which are increasingly widespread today.
Let's start by using the sheet that we need to download from the site, which provides customers with both quick guides and the complete manual to perform an advanced configuration of our players.
Datalogic Scanner Manual Configuration
To configure a Datalogic barcode reader , you will first need to connect the USB cable that will connect the PC and the scanner gun, let's take the Datalogic Quickscan QD2430 model as an example. Once this is done, the first thing to do will be to proceed with an initial reading from the sheets in our possession, which contain 2D codes.
The first code to read will be the one corresponding to the wording “usb keyboard with standard key encoding” ; after which we can move on to the next reading, positioning our scanner gun on the 2d code corresponding to “enter/exit programming mode” , that is , entering/exiting programming mode .
Below we will enable reading from a Smartphone by framing the code "mobile phone mode: enable" , which corresponds to the Italian " cell phone mode: enable" and then finally return to the previous code to enter/exit programming mode , which will conclude all the steps to be performed in order to use our barcode reader.
In this way our Datalogic barcode reader will be configured, and to test it it will be enough to read a barcode on any object, such as a product present in the house, and a code present on the smartphone, such as that of loyalty cards, thus being able to display them on the PC screen.
In this way, by following this configuration procedure, we will be able to use both the English manual and the Italian manual.
The different types of code
Today there are mainly two types of barcodes , and consequently the readers have had to adapt to allow their use in every eventuality, each with different optical groups suitable for 1D codes, the classic linear ones, and 2D codes, but while those suitable for the latter can also read the former, the reverse is not possible.
To be clear, 1d codes are linear , that is, those composed of a sequence of black bars and spaces that surmount a series of numbers, the first 3 identify the country of origin of the product, the following 4 indicate the address of the manufacturer or supplier, the other 5 refer to the item itself indicating the type of product, the weight and the packaging, and finally the last number which is added only to facilitate reading the barcode.
There are different 2D codes, imagers , which are the so-called QR codes, of the new generation, or Data Matrix, which are very similar in appearance but have some small differences.
At first glance they consist of a set of black and white square modules, they both contain an infinite amount of information that the barcode reader will be able to read, but they have different capacities.
Every object has its own identifying barcode, and every Datalogic reader will be able to decipher it.
